GUT MMF 17, Astro
GUT MMF 17, AstroGUT MMF 17, AstroGUT MMF 17, Astro
Images may differ

GUT MMF 17, Astro

Product number: 81541174

GUT MMF 17, 2-Port Modem trunkline wall outlet for multimedia, CATV and data, 5 – 1800 MHz, Tap loss 17 dB

  • Tap loss: 17 dB
  • 5 – 1800 MHz for future expansion of Docsis 3.1 and MoCA application (TV up to 862 MHz)
  • improved EMC properties through compliance with class A + 10 dB (LTE safe)
  • with 85 MHz filter, decoupling > 37 dB up to 204 MHz (with MMF 8 - 20) for Docsis 3.1 return path application
  • fast and secure clamping technology even with different cable cross-sections
  • cable kink protection due to rounded housing shape
  • F connector for connecting a modem
  • complies with Vodafone specification VFKD TS 142
  • complies with UM TS 414 with 160 VDC overvoltage protection
